Zoom G6 User Manual

Making audio interface settings
The recording levels can be adjusted and the monitoring balance can be set, for example.
1.
Touch on the Menu Screen.
2.
Make audio interface settings.
■Adjusting the volume (recording level) sent to the computer
Turn or drag the RECORDING GAIN knob up and down to adjust the recording level.
The setting values are shown above the knobs.
HINT
The setting range is −6 dB to +6 dB.
91

Zoom G6 Specifications

General

Amp Models	22
IR Loader	Yes
Pedal Type	Multi-effects
Amp Modeling	Yes
Bluetooth	No
Display	4.3-inch color touchscreen
Looper	2 hours
Inputs	1 x 1/4" (aux in)
Outputs	2 x 1/4" (main out), 1 x 1/4" (phones)
Power Supply	9V DC 500mA power supply (included)
Effects Types	Delay, Reverb, Modulation, Distortion
Processor	Custom Zoom ZFX-IV DSP
Weight	1.9 kg
