ZXR108900SeriesHardwareInstallationManual
thecircuitisanopencircuit.Iftheresultshowsthatitisnot
anopencircuit,thenthecabinetisnotinsulatedwithearth.
Examinetheinsulatedtube.Repeatthelaststepandinsula-
tiontest.
Note:
Insulationtesthastobeimplementedimmediatelyaftereach
cabinetfootingisxed.
Result:Cabinethasbeeninstalledbyadjustablebase.
InstallingCabinetonFloorDirectly
Toinstallcabinetonoordirectly,performthefollowingsteps.
1.CabinetHeightRegulation
AsshowninFigure35,loosenthefourboltsthatfastenthe
trucklesandthenremovethetruckles.Loosenthefourlock-
nutsoffooting.Placethecabinetonthecorrespondingposition
oftheedgeexpansionboltonNOCroomoormanuallyorby
liftingmachine.Makesurethattheright,left,frontandback
planeofcabinetareparallelwiththeNOCroomwalls.Usethe
heightadjustingnutonfootingtoregulatetheheightofcabi-
net.
Afterinstallingthepanelwood,thereis5mmclearancebe-
tweenthebottomofpanelwoodandoor ,asshowninFigure
35.
FIGURE35THECLEARANCEBETWEENPANELWOODANDFLOOR
1.Cabinet
2.PanelWood
3.Floor
2.CabinetLeveling
Thecabinetmustbeverticallyinstalled.Placelevelbaron
thetwoperpendiculardirectionsofcabinettoppanel.Usethe
heightadjustingnuttoregulatethehorizontalityandvertical-
ityofcabinet.Installedhorizontalityandverticalitydeviation
42CondentialandProprietaryInformationofZTECORPORATION

Zte ZXR10 8900 Series Specifications

General

Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Ports	10/100/1000BASE-T
Layer Support	Layer 2 and Layer 3
VLAN Support	4K VLANs
QoS	8 priority queues per port
Management	CLI, Web, SNMP, RMON
Power Supply	AC or DC
Redundancy	Power supply redundancy, fan redundancy
