Zte ZXR10 8900 Series Hardware Installation Manual

Chapter5MasterDeviceInstallation
UnplugFan
Plug-inBox
Tounplugfanplug-inboxofZXR108902,performthefollowing
steps.
1.Loosenthecaptivescrewsontheupperandlowersideofthe
fanplug-inboxusingacrossscrewdriver .
2.Catchholdofthehandleofthefanplug-inboxandpullthebox
outforcibly.
Result:Fanplug-inboxofZXR108902hasbeenunplugged.
InstallationofCablingRack
Cablingrackisprovidedforcablinginengineeringinstallationwith
ZXR108912,ZXR8908orZXR108905.Cablingrackincludes
verticalsupporterandhorizontalcableplate.Verticalsupporteris
necessaryandhorizontalcableplateisoptional.
InstallingVerticalSupporter
ZXR108912,ZXR108908andZXR108905adoptthesame
methodtoinstallverticalsupporter .T akeZXR108908foran
exampletointroducehowtoinstallverticalsupporter .
�Installverticalsupporterincabinet
Makesurethattheplug-inboxhasbeenpluggedincabinetal-
readybeforeverticalsupporterisinstalled.Keepwaist-round
holesofverticalsupporterandthatofplug-inboxonthesame
line,xtheverticalsupporterincabinetwiththreecrown
screws,fastenthecrownscrews,asshowninFigure77.
CondentialandProprietaryInformationofZTECORPORATION79

Zte ZXR10 8900 Series Specifications

General

Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Ports	10/100/1000BASE-T
Layer Support	Layer 2 and Layer 3
VLAN Support	4K VLANs
QoS	8 priority queues per port
Management	CLI, Web, SNMP, RMON
Power Supply	AC or DC
Redundancy	Power supply redundancy, fan redundancy
