ZXR108900SeriesHardwareInstallationManual

FIGURE44REINSTALLATIONTHEANGLESUPPORT

4.Betweentwonearcabinets,usesixscrewsM8×12,atwasher ,

springwasherandM8nuttoconnectanglesupport.Thein-

stallationoftwonearcabinetsisshowninFigure45.

FIGURE45CONNECTIONBETWEENTWONEARCABINETS

1.SixscrewsM8×12

2.Springwasher

3.Flatwasher

4.Anglesupport

5.M8nut

5.Afterconnectingthecabinets,xthecabinet.Ifthecabinetis

installedbyanadjustablebase,pressthefootingwithpressure

plate.FixthepressureplateonadjustablebasewithM12×30

screws.Asaresult,thefootingsarexed.Ifthecabinetis

installedonoordirectly,pressthefootingwithpressureplate,

andxthepressureplateonexpansionboltonoor .Asa

result,thecabinetisxed.

6.Installcabinetsorderlyaccordingtostep5.Fixallfootings.

7.Inspectthesupportconditionofeachfooting.

Result:Thecabinetshavebeenconnected.

50CondentialandProprietaryInformationofZTECORPORATION
