Chapter 38 Product Specifications
MES-3728 User’s Guide
302
Configuration Backup &
Restoration
Make a copy of the Switch’s configuration and put it back on the Switch
later if you decide you want to revert back to an earlier configuration.
Cluster Management Cluster management (also known as iStacking) allows you to manage
switches through one switch, called the cluster manager. The switches
must be directly connected and be in the same VLAN group so as to be
able to communicate with one another.
Table 118 Firmware Specifications
FEATURE DESCRIPTION
Table 119 Feature Specifications
Layer 2
Features
Bridging 16K MAC addresses
Static MAC address filtering by source/destination
Broadcast storm control
Static MAC address forwarding
Switching Switching fabric: 12.8 Gbps, non-blocking
Max. Frame size: 9 K bytes
Forwarding frame: IEEE 802.3, IEEE 802.1q, Ethernet II, PPPoE
Prevent the forwarding of corrupted packets
STP IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
Multiple Rapid Spanning Tree capability (2 configurable trees)
IEEE 802.1s Multiple Spanning Tree Protocol
QoS IEEE 802.1p
SPQ, WRR, WFQ, SPQ/WRR or SPQ/WFQ combination capable
Eight priority queues per port
Rule-based bandwidth control (ingress traffic metering/dropping 64Kb stepping)
Port-based egress traffic shaping
Rule-based traffic mirroring
IGMP snooping
TRTCM
VLAN Port-based VLAN
802.1Q tag-based VLAN
number of VLAN: 4K, 2000 static maximum
GVRP for dynamic registration
Double tagging for VLAN stacking
Private VLAN for port isolation.
Protocol-Based VLAN.
IP subnet based VLAN
Port
Aggregation
IEEE 802.3ad LACP
Six groups (up to eight ports each)
Port mirroring Rule-based port mirroring
Port-based mirroring
Support port mirroring per IP/TCP/UDP
Bandwidth
control
Supports rate limiting at 64 Kb increments
TRTCM
