Installation manual 2N® IP Verso
•
•
•
•
•
•
•
•
•
•
•
Caution
Make sure that the diameter of the dowel holes is accurate to avoid falling out of
the dowels! Use the mounting glue to secure the dowels if necessary.
Make sure that the depth of the dowel holes is accurate!
Do not use low-quality dowels to avoid their pulling out of the wall!
Having removed the front panel, make sure that no dirt gets inside the product
(especially onto the sealing surface).
Never turn 2N
®
IP Verso to align the box assembly after mounting. Make sure that
the flush mounting boxes have been installed accurately.
Check the plasterboard wall and room interior pressure values. If the difference
between the values is too great (as a result, e.g., of overpressure ventilation),
separate the intercom using, for example, the mounting box enclosed and seal the
cable passage to avoid speaker damage.
Surface mounting may cause problems on places exposed to potential vandalism
(such as public garages, etc.). In this case, use steel anchoring elements instead of
the dowels and screws included in the delivery.
Make sure that the installation surface is perfectly flat with the maximum
inequality of 0.5 mm. (e.g. boards, glass, cut stone, etc). If this is not the case, use a
mounting backplate Part No 9155061–9155067, or level the wall surface.
Always use an installation backplate for uneven installation surfaces.
While flush mounting, make sure that the box is installed properly, i.e. with the box
frame on the wall surface. There are snap-off protrusions on both sides of the flush
mounting box to facilitate positioning. Make sure that the frame is placed precisely
onto the flush mounting box off the wall to provide effective sealing and avoid
water penetration into the intercom. Refer to the pictorial instructions inside the
flush mounting box package.
Any intentional mechanical damage (drilling, main unit tampering, etc.) results in a
loss of warranty.
