Jet Wiper Assembly Material Cartridge 2
Material Cartridge 1 Material Cartridge 3
NOTE: The following image illustrates the second and third cartridge bays of a
CubePro Trio.
Material Tube Material Cartridge Mount Rings
Clamp Rollers Material Cartridge Bay 2
Cartridge Recognition
Connections
Material Cartridge Bay 3
Material Cartridge Bay 2 Hinge
To Next Page
