REMOVING THE REMAINING PACKAGING MATERIALS
1. Using left / right arrows on the touch screen, navigate to the MOVE menu. (Fig. 18)
Fig. 18
Fig. 19
2. Using the up arrow on the right side of screen, move the print plate up far enough to
remove the foam. (Fig. 19)
Fig. 20
3. Remove the last foam piece underneath the build plate. (Fig. 20)
Fig. 21
4. Move the Print Pad all the way down to install the Jet Wiper. (Fig. 21)
Fig. 22
5. To install the Print Wiper, insert the wiper’s two key holes onto the two rods located
at the back, right side of printer. The wiper’s white plastic piece and spring should be
facing the front. (Fig. 22)
11
