20
VIEW TAB
SETTINGS TAB
ZOOM Zoom In Press to zoom in
Zoom Out Press to zoom out
VIEW Top View Press to view the part from above
Front View Press to view the part from the front
Left View Press to view the part from the left
Right View Press to view the part from the right
PRINT PATHS Show Print Jet 1 Toggle to show the print paths for print jet
1 in a .cubex le
Show Print Jet 2 Toggle to show the print paths for print jet
2 in a .cubex le
Show Print Jet 3 Toggle to show the print paths for print jet
3 in a .cubex le
Show All Layers Toggle to show all layers or to show one
layer at a time. Scroll through the layers
using the scroll bar found down the right
hand side of the window
PRINTER
CONFIGURATION
Opens the printer conguration window.
BUILD SETTINGS Opens the build settings window.
FIRMWARE UPDATE Used to update the CubeX 3D Printer rmware.
WARNING: PRINT JET TIPS BECOME EXTREMELY HOT DURING SET-UP AND OPERATION. DO NOT
TOUCH PRINT JET TIP.
DO NOT CHANGE CARTRIDGE COLOR OR MATERIAL TYPE DURING PRINTING; DOING SO MAY DAMAGE
THE CUBEX.
HOW TO OPEN FILES IN THE CUBEX SOFTWARE
The CubeX software has three different possible ways to open .stl les. A single part le, multiple single part les on one
Print Pad and a multi-part le assembly.
• A single part le consists of one .stl le with one shell on a Print Pad.
CREATION FILE PREPARATION & PRINTING YOUR CREATIONS
!
