The CubeX 3D Printer creates the model by pulling lament from the cartridge through the print jets via the delivery tubes.
The lament is then jetted through the print jet tip in a thin string of molten plastic. The print jet movement is coordinated
by the print plate, which lowers incrementally after each layer is deposited so a new layer can be drawn on top of the last,
building the part up.
CUBEX 3D PRINTER PROPERTIES
• Plastic Jet Printing technology
• Houses up to three print jets for multi-color and multi-material prints
• Choice between ABS and PLA plastic, both recyclable
• Prints objects up to 275 x 265 x 240 mm (10.75”x10.5”x9.5”)
• EZ load print cartridge
• Fully automated supports: peel off supports for ABS and PLA; PLA supports can also be removed using the Ultrasonic
Support Removal Tank available at Cubify.com/cubex/store_parts.aspx
PRINT MATERIALS
The CubeX can use two different types of print materials: PLA and ABS. Each material has unique benets and you can
guide your selection based on the properties your part requires.
CUBEX 3D PRINTER FEATURES AND BENEFITS
Glow-in-the-
dark Neon
Green
* Natural is only available in PLA plastic, not ABS.
Neon Orange
Glow-in-the-
dark Neon
Blue
Tan
White
Yellow
Black
Neon Green
Silver
Green
Industrial Grey
Blue
Natural*
Teal
Magenta
Purple
Red
Brown
PLA This is a hard plastic that has a low environmental impact. It is derived from renewable, starch-based
resources.
We recommend using PLA when printing extra-large parts on CubeX as it is a more stable print
material.
PLA is the optimal support material for industrial ABS parts. PLA has the ability to dissolve away in
caustic soda solutions supported by an ultra-sonic tank. (see page 36 for more information)
ABS This is a well-known plastic known for its strength and industrial properties.
As a build material, ABS is good for both small and large parts.
ABS works as an excellent support material for extra-large PLA parts.
MATERIAL COLOR CHOICES
5
