2. Use the Magic CubeX Glue to coat the Print Pad with a layer

of glue. Turn the CubeX Glue upside down so the glue ows

to the tip. (Fig. 88)

3. Apply 3 layers of Magic CubeX Glue using a slow circular

motion. If the print is large, ensure that the glue covers the

Print Pad surface where the creation will print. If it is a smaller

print, cover the middle of Print Pad with the glue. (Fig. 89)

SAVING A .CUBEX FILE FOR PRINTING

1. Click the Save Print File button. (Fig. 85)

PRINTING YOUR CREATION

1. When you are ready to print your creation, insert the USB stick containing your .cubex

le into the USB port on the CubeX. (Fig. 87)

Fig. 85

Fig. 86

Fig. 87

Fig. 88 Fig. 89

Fig. 90 Fig. 91

PART MATERIAL Similar to Printer Conguration, this tells the software which materials are loaded into

which print jets. Part materials works in a similar way to Printer Conguration, telling

the software which materials are loaded into which print jets. Please be sure that

the materials selected in part materials correspond to the print jets the materials are

allocated too.

BUILD Once you have selected all of your preferences, press the build button to create the

.cubex le.

2. Your le can be saved on the USB stick or your computer. Choose the location

you wish to save the .cubex le, give it a suitable name and click “Save.”

Transfer the .cubex le to your USB stick for printing or save it on your USB

stick. (Fig. 86)

4. Select the ‘Print’ option from the main menu. (Fig. 90)

5. Using the arrows at the bottom of the screen, scroll to the

.cubex le you wish to print and tap on the le name. Your

creation will start printing. (Fig. 91)

3D Systems CubeX Duo User Manual
