Bridge Mode Traffic Classification Settings
TRAFFIC CLASSIFICATION
VLAN bridge mode traffic classification settings provide mapping / assigning of profiles (set by rules to match
a specific traffic type) to a VLAN ID and VLAN CoS / priority. The profile which is used to match to a specific
traffic type will be identified in the radio network by its associated VLAN ID and VLAN CoS / priority to
provide the appropriate QoS treatment. CoS / Priority can be set to Very High, High, Medium and Low
priority.
Profile name
A free form field to enter the profile name with a maximum of 32 chars.
Assigned Priority
Traffic packets that match the applied profile rules will be assigned to the selected ‘assigned priority’
setting of Very High, High, Medium and Low. This field cannot be set to Don’t Care.
This applies profile rule mapping to the VLAN CoS / Priority with the appropriate internal radio assigned
priority setting of Very High, High, Medium and Low priority.
