4RF Aprisa SR+ - USB RS-232 Cabling Options; USB RS-485 Cabling Options

Product Options | 435
Aprisa SR+ User Manual 1.11.1
USB RS-232 Cabling Options
The following converter cables are available as Aprisa SR+ accessories to provide the customer interface.
The kit contains a USB connector retention clip (see ‘USB Retention Clip’ on page 436).
1. USB Converter to 1.8 metre multi-strand cable 6 wire for termination of customer connector
Part Number
Part Description
APSB-KFCA-USB-23-MS-18
4RF SR+ Acc, Kit, Interface, USB Conv, RS-232, Multi-strand, 1.8m
2. USB converter to RJ45 female kit for USB to RS-232 DCE conversion.
Part Number
Part Description
APSB-KFCA-USB-23-45-MF18
4RF SR+ Acc, Kit, Interface, USB Conv, RS-232, RJ45, Female, 1.8m
3. USB converter to DB9 female kit for USB to RS-232 DCE conversion.
Part Number
Part Description
APSB-KFCA-USB-23-D9-MF18
4RF SR+ Acc, Kit, Interface, USB Conv, RS-232, DB9, Female, 1.8m
USB RS-485 Cabling Options
The following converter cable is available as an Aprisa SR+ accessory to provide the customer interface RS-
485 2 wire. The kit contains a USB connector retention clip (see ‘USB Retention Clip’ on page 436).
1. USB Converter to 1.8 metre multi-strand cable 6 wire for termination of customer interface
Part Number
Part Description
APSB-KFCA-USB-48-MS-18
4RF SR+ Acc, Kit, Interface, USB Conv, RS-485, Multi-strand, 1.8m
