Aprisa SR+ User Manual 1.11.1
Protected Station with Duplexer Kit
This product option combines the Aprisa SR+ Protected Station and a Duplexer Kit in one part number.
Option Example for 700 MHz:
4RF SR+, PS+D, 757-788 MHz, E0 Kit, Half Dup, 2E2S, EN, 48VDC
Aprisa SR+ Protected Station, half duplex RF option
2 Ethernet ports and 2 Serial ports
Software Selectable Channel Sizes of 25 kHz, 50 kHz and 100 kHz
FCC Part 27
Single antenna operation
18 - 60 VDC floating input power
Aprisa SR+ Duplexer Kit for a Aprisa SR+ Protected Station containing:
1x 1U 19" rack front mount shelf with duplexer mounting brackets and
screws
1x E0 Duplexer 700 MHz, min split 30 MHz, p 7.0 MHz , N type female
antenna connector
2x right angle TNC to SMA right angle 640mm cables
