Aprisa SR+ User Manual 1.11.1
Cabling
The Aprisa SR+ Protected Station is delivered pre-cabled with power, interface, management and RF cables.
There are two options for the pre-cabled Protected Station (see ‘Antenna and Duplexer Options’):
1. Standard Protected Station- suitable for options #1 and #2 (single antenna operation)
4RF SR+, PS, 400-470 MHz, SSC, Half Duplex, 2E2S, EN, STD
2. Dual Antenna Protected Station- suitable for options #3 and #4 (dual antenna operation)
4RF SR+, PS, 400-470 MHz, SSC, Half Duplex, 2E2S, EN, Dual Ant
Each option (per ordered part number) is pre-cable configured as the following:
Internal pre-cabled Protected Station wiring setting
Standard Protected Station
(single antenna operation)
Dual Antenna Protected Station
(dual antenna operation)
