Initial Network Deployment
Install the Base Station
To install the base station in your network:
1. Install the base station radio (see ‘Installing the Radio’ on page 80).
2. Set the radio Network ID to a unique ID in your entire network (see ‘Terminal > Device’ on page 111).
3. Set the radio operating mode to ‘base station’ (see ‘Terminal > Operating Mode’ on page 119).
4. Set the radio IP address (see ‘IP > IP Setup > Bridge / Gateway Router Modes’ on page 183).
5. Set the radio frequencies to the frequencies you wish to operate from (see ‘Radio > Radio Setup’ on
page 129).
6. Set the radio security settings (see ‘Security > Setup’ on page 227).
Installing the Remote radios
To install the remote radios in your network:
1. Install the remote radio (see ‘Installing the Radio’ on page 80).
2. Set the radio Network ID to the same ID as the other stations in the network (see ‘Terminal > Device’
on page 111).
3. If repeater used in radius 1, set the network radius=2 on all network stations (see ‘Terminal > Device’
on page 111).
4. Set the radio operating mode to ‘remote radio’ (see ‘Terminal > Operating Mode’ on page 119).
5. Set the radio IP address (see ‘IP > IP Setup > Bridge / Gateway Router Modes’ on page 183).
6. Set the radio frequencies to the base station / repeater station frequencies you wish to operate from
(see ‘Radio > Radio Setup’ on page 129).
7. Set the radio security settings to the same as the base station (see ‘Security > Setup’ on page 227).
The base station will automatically allocate a node address to the new remote radio.
Install a Repeater Station
To install a repeater station in your network:
1. Install the repeater station radio (see ‘Installing the Radio’ on page 80).
2. Set the radio Network ID to the same ID as the other stations in the network (see ‘Terminal > Device’
on page 111).
3. Increase the radio network radius by one on all stations in the network (see ‘Terminal > Device’ on page
111).
4. Set the radio operating mode to ‘repeater station’ (see ‘Terminal > Operating Mode’ on page 119).
5. Set the radio IP address (see ‘IP > IP Setup > Bridge / Gateway Router Modes’ on page 183).
6. Set the radio frequencies to base station frequencies you wish to operate from (see ‘Radio > Radio
Setup’ on page 129).
7. Set the radio security settings to the same as the base station (see ‘Security > Setup’ on page 227).
The base station will automatically allocate a node address to the new repeater station.
