Aprisa SR+ User Manual 1.11.1
Advanced Gateway Router (AGRM) or Advanced Router Mode (ARM) Static Route – Example
The purpose of this example is to determine the static route setting for router R2 in the base station and
remote radio in the following AGRM-Bridge, Bridge-AGRM networks.
In the above figure, the static route setting for router R2 at the base radio AGRM will be:
In the above figure, the static route setting for router R2 at the remote radio AGRM will be:
In the above figure, the static route setting for router R2 at the Base Station AGRM will be:
Note: In AGRM / ARM - AGRM / ARM network scenario, automatic route build of the radio network is currently
not supported. Auto route build for the associated devices to the radio network (i.e. next hop devices) is
only supported in the standard router modes where the base station, repeater and remote radios are all in
standard router modes.
