VCCX2 Controller Technical Guide
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
PreHeat
Enable
Setpoint
AV: 29 If the Supply Fan is
energized this is the
temperature at which the
Preheat Relay will acti-
vate or the Preheat-X
Controller will activate.
Operates only in the
Occupied Mode.
-30°F
-34.4°C
70°F
21.1°C
Sensor Slide
Oset Max
Eect
AV: 30 If your space sensor has
the optional slide
adjustment feature, this is
the maximum amount the
slide can adjust the
current heating and
cooling setpoints up or
down with full deection
of the slide.
0°F
0°C
10°F
5.5°C
Space Sensor
Calibration
Oset
AV: 31 If the Space Temperature
Sensor is reading
incorrectly, you can use
this option to enter an o-
set temperature to adjust
the Sensor’s Temperature.
-100°F
-55.5°C
100°F
55.5°C
Supply Air
Sensor
Calibration
Oset
AV: 32 If the Supply Air
Temperature Sensor is
reading incorrectly, you
can use this option to en-
ter an oset temperature
to adjust the Sensor’s
Temperature.
-100°F
-55.5°C
100°F
55.5°C
Return Air
Sensor
Calibration
Oset
AV: 33 If the Return
Temperature Sensor is
reading incorrectly, you
can use this option to en-
ter an oset temperature
to adjust the Sensor’s
Temperature.
-100°F
-55.5°C
100°F
55.5°C
Outdoor Air
Sensor
Calibration
Oset
AV: 34 If the Outdoor
Temperature Sensor is
reading incorrectly, you
can use this option to en-
ter an oset temperature
to adjust the Sensor’s
Temperature.
-100°F
-55.5°C
100°F
55.5°C
Carbon
Dioxide
Sensor
Calibration
Oset
AV: 35 If the CO
2
Sensor is
reading incorrectly, you
can use this option to
enter an oset value to
adjust the Sensor’s CO
2
reading.
-500 500
Low Ambient
Protection
Setpoint
AV: 36 Temperature at which the
Low Ambient Relay will
activate in the Occupied
or Unoccupied Mode.
-30°F
-34.4°C
70°F
21.1°C
SAT Cool
Setpoint
Reset Source
Low Limit
AV: 37 If doing Supply Air
Setpoint Reset, this is the
Low Reset Source value
in Cooling that will
correspond to the Supply
Air Cool High Reset
Setpoint.
-30°F
-34.4°C
150°F
65.5°C
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
SAT Cool
Setpoint
Reset Source
High Limit
AV: 38 If doing Supply Air
Setpoint Reset, this is the
High Reset Source value
in Cooling that will
correspond to the Supply
Air Cooling Setpoint
(Low Reset).
0°F
-17.7°C
150°F
65.5°C
SAT Heat
Setpoint
Reset Source
Low Limit
AV: 39 If doing Supply Air
Setpoint Reset, this is the
Low Reset Source value
in Heating that will
correspond to the
Supply Air Heating High
Reset Setpoint.
-30°F
-34.4°C
150°F
65.5°C
SAT Heat
Setpoint
Reset Source
High Limit
AV: 40 If doing Supply Air
Setpoint Reset, this is
the High Reset Source
value in Heating that will
correspond to the Supply
Air Heating Setpoint
(Low Reset).
0°F
-17.7°C
150°F
65.5°C
Control
Temperature
High Alarm
Oset
AV: 41 If the temperature of the
controlling sensor rises
above the Occupied
Cooling Setpoint by this
value, a High Control
Temp Alarm will occur.
Only applies if cong-
ured for Space or Return
Air Temp Control, or as
Single Zone VAV.
0°F
0°C
50°F
27.7°C
Control
Temperature
Low Alarm
Oset
AV: 42 If the temperature of the
controlling sensor falls
below the Occupied
Heating Setpoint by this
value, a Low Control
Temp Alarm will occur.
Only applies if cong-
ured for Space or Return
Air Temp Control, or as
Single Zone VAV.
0°F
0°C
50°F
27.7°C
Heat Pump
Compressor
Heat Lockout
AV: 43 Compressor Heat will
be locked out below this
setpoint.
-30°F
-34.4°C
100°F
37.7°C
Maximum
Main Fan
VFD in
S Z VAV
Heating
Mode
AV: 44 In Single Zone VAV
conguration, this is the
max fan speed the VFD
can modulate up to in
Heat Mode.
0 100
APPENDIX C
-
VCCX2 BACnet
®
VCCX2 BACnet
®
Parameters
