VCCX2 Controller Technical Guide
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
Low Control
Mode Alarm
BI: 37 Occurs when the
Controlling Sensor
Temperature falls below
the Heating Mode Enable
Setpoint minus the
Control Mode Low Alarm
Oset. Applies only to
Space or Return Air Tem-
perature controlled units.
Missing
Refrigerant
Module #1
BI: 38 Refrigerant Module #1 is
bad or missing.
Missing
Refrigerant
Module #2
BI: 39 Refrigerant Module #2 is
bad or missing.
Missing
Refrigerant
Module #3
BI: 40 Refrigerant Module #3 is
bad or missing.
Missing
Refrigerant
Module #4
BI: 41 Refrigerant Module #4 is
bad or missing.
Missing
Preheater
Board
BI: 42 Preheater Module is bad
or missing.
Missing
Reheat Board
BI: 43 The MHGR board is
congured but not
detected.
Missing Mod
Gas Board
BI: 44 The MODGAS board
is congured but not
detected.
Missing EM1
Board
BI: 45 EM1 Expansion Board is
bad or missing.
Missing 12
Relay
Expansion
Board
BI: 46 The 12 Relay Expansion
Board is congured but
not detected.
On Board
Relay 1 Main
Fan
BI: 47 Current Status of Main
Fan Relay #1 on Main
Board
On Board
Relay 2
BI: 48 Current Status of
Congurable Relay #2 on
Main Board
On Board
Relay 3
BI: 49 Current Status of
Congurable Relay #3 on
Main Board
On Board
Relay 4
BI: 50 Current Status of
Congurable Relay #4 on
Main Board
On Board
Relay 5
BI: 51 Current Status of
Congurable Relay #5 on
Main Board
On Board
Relay 6
BI: 52 Current Status of
Congurable Relay #6 on
Main Board
On Board
Relay 7
BI: 53 Current Status of
Congurable Relay #7 on
Main Board
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
On Board
Relay 8
BI: 54 Current Status of
Congurable Relay #8 on
Main Board
Expansion
Board EM1
Relay 1
BI: 55 Current Status of
Congurable Relay #1 on
EM1 Board
Expansion
Board EM1
Relay 2
BI: 56 Current Status of
Congurable Relay #2 on
EM1 Board
Expansion
Board EM1
Relay 3
BI: 57 Current Status of
Congurable Relay #3 on
EM1 Board
Expansion
Board EM1
Relay 4
BI: 58 Current Status of
Congurable Relay #4 on
EM1 Board
Expansion
Board EM1
Relay 5
BI: 59 Current Status of
Congurable Relay #5 on
EM1 Board
12 Relay
Expansion
Board Relay 1
BI: 60 Current Status of
Congurable Relay #1 on
12 Relay Board
12 Relay
Expansion
Board Relay 2
BI: 61 Current Status of
Congurable Relay #2 on
12 Relay Board
12 Relay
Expansion
Board Relay 3
BI: 62 Current Status of
Congurable Relay #3 on
12 Relay Board
12 Relay
Expansion
Board Relay 4
BI: 63 Current Status of
Congurable Relay #4 on
12 Relay Board
12 Relay
Expansion
Board Relay 5
BI: 64 Current Status of
Congurable Relay #5 on
12 Relay Board
12 Relay
Expansion
Board Relay 6
BI: 65 Current Status of
Congurable Relay #6 on
12 Relay Board
12 Relay
Expansion
Board Relay 7
BI: 66 Current Status of
Congurable Relay #7 on
12 Relay Board
12 Relay
Expansion
Board Relay 8
BI: 67 Current Status of
Congurable Relay #8 on
12 Relay Board
12 Relay
Expansion
Board Relay 9
BI: 68 Current Status of
Congurable Relay #9 on
12 Relay Board
12 Relay
Expansion
Board Relay 10
BI: 69 Current Status of
Congurable Relay #10
on 12 Relay Board
12 Relay
Expansion
Board Relay 11
BI: 70 Current Status of
Congurable Relay #11
on 12 Relay Board
12 Relay
Expansion
Board Relay 12
BI: 71 Current Status of
Congurable Relay #12
on 12 Relay Board
Preheater
Enable Status
BI: 72 Status of Preheater
Enable Input
APPENDIX C
-
VCCX2 BACnet
®
VCCX2 BACnet
®
Parameters
