ABB A43

Communication with Modbus
2CMC48001M0201 117 A43/A44
Revision: C User Manual
DMTME
multimeters
Quantity
Details
Start
Size
Action
Data type
Reg
(hex)
Reset Load profile
8F23
1
Write the value 1 to
Unsigned
channel 3
perform a reset
Reset Load profile
8F24
1
Write the value 1 to
Unsigned
channel 4
perform a reset
Reset Load profile
8F25
1
Write the value 1 to
Unsigned
channel 5
perform a reset
Reset Load profile
8F26
1
Write the value 1 to
Unsigned
channel 6
perform a reset
Reset Load profile
8F27
1
Write the value 1 to
Unsigned
channel 7
perform a reset
Reset Load profile
8F28
1
Write the value 1 to
Unsigned
channel 8
perform a reset
Reset System log
8F31
1
Write the value 1 to
Unsigned
perform a reset
Reset Event log
8F32
1
Write the value 1 to
Unsigned
perform a reset
Reset Net quality log
8F33
1
Write the value 1 to
Unsigned
perform a reset
Freeze demand
8F70
1
Write the value 1 to
Unsigned
freeze the demand
values
Parts of the Modbus mapping is compatible with the ABB DMTME
multimeters. All registers in the following table are read only:
Quantity
Start Reg (Hex)
Size
Unit
Data type
Phase Voltage L1-N
1002
2
Volt
Unsigned
Phase Voltage L2-N
1004
2
Volt
Unsigned
Phase Voltage L3-N
1006
2
Volt
Unsigned
Line Voltage L1-L2
1008
2
Volt
Unsigned
Line Voltage L2-L3
100A
2
Volt
Unsigned
Line Voltage L1-L3
100C
2
Volt
Unsigned
Line Current L1
1010
2
mA
Unsigned
Line Current L2
1012
2
mA
Unsigned
Line Current L3
1014
2
mA
Unsigned
