ABB A43

Communication with Modbus
A43/A44 160 2CMC48001M0201
User Manual Revision: C
Week profile
configuration
registers
Step Action
3 Repeat step 2 for each season, until all season configurations have been read.
This means step 2 shall be performed the same number of times as the value
read in step 1.
Note – Step 1 initiates the readout procedure and can NOT be left out, even if
the number of seasons used is already known.
Note – The Season number register can optionally be read together with the
Season registers in step 2. The Season number register holds the current season
number, starting from 1 after reading the Number of seasons register. It is
incremented every time the Season registers are read.
The following table describes the group of registers for configuring week profiles:
Function
Start
Size
Description
Read/
Reg
write
(Hex)
Number of week
8CB5
1
The number of week profiles used (1-4)
R/W
profiles
Week profile
8CB6
1
Current week profile number during read
R
number
or write of configuration
Week profile
8CB7
22
Name and day IDs for the week profile
R/W
Week profile
registers
The following table describes the group of registers for configuring a
week profile:
Function
Start
Size
Description
Read/
Reg
write
(Hex)
Week profile
8CB7
15
The week profile name. Same format as
R/W
name
described in Season registers above.
Day ID monday
8CC6
1
Day ID for monday. Allowed values are
R/W
1-16.
Day ID ...
...
1
...
R/W
Day ID sunday
8CCC
1
Day ID for sunday. Allowed values are 1-
R/W
16.
Note – All 22 registers in the table above must be written in one operation, otherwise
the values will not take effect.
Note – If the tariff configuration has been performed using any other communication
protocol, other values than 1-16 can occur for Day IDs. When configuring over Mod-
bus though, the values written have to be within this range.
