Communication with Modbus
A43/A44 162 2CMC48001M0201
User Manual Revision: C
Follow the steps in the table below to configure the week profiles:
Write the number of week profiles to use to the Number of week profiles
register. This is a value between 1 and 4.
Write the desired week profile configuration of the first week profile to the Week
Repeat step 2 for all week profiles that shall be used, i.e. the same number of
times as the value written in step 1.
Read week profile
configuration
Day profile
configuration
registers
Follow the steps in the table below to read the current week profile configuration:
Read the Number of week profiles register to find out how many week profiles
Read from the Week profile registers to get the week profile name and day ID:s
for the first week profile.
Repeat step 2 for each week profile, until all week profile configurations have
been read. This means step 2 shall be performed the same number of times as
the value read in step 1.
Note – Step 1 initiates the readout procedure and can NOT be left out, even if
the number of week profiles used is already known.
Note – The Week profile number register can optionally be read together with the
Week profile registers in step 2. The Week profile number register holds the current
week profile number, starting from 1 after reading the Number of week profiles
regis-ter. It is incremented every time the Week profile registers are read.
The following table describes the group of registers for configuring day profiles:
The number of day profiles used (1-16)
Current day profile number during read
or write of configuration
The number of actions during a day
Current action number during read or
Time when the action shall be
performed, and what to do
