ABB A43

Communication with M-Bus
A43/A44 176 2CMC48001M0201
User Manual Revision: C
Register
Communication objects
Inputs, current state
Read current state of input 1,2, 3 and 4
Inputs, stored state
Read and reset stored state of input 1,2, 3 and 4
Inputs, counter
Read and clear input pulse counter 1,2, 3 and 4
Current N
Instantaneous current in the neutral wire
Current, L1
Instantaneous current in the L1 phase
Current, L2
Instantaneous current in the L2 phase
Current, L3
Instantaneous current in the L3 phase
Voltage, L1-N
Instantaneous voltage between L1 and neutral
Voltage, L2-N
Instantaneous voltage between L2 and neutral
Voltage, L3-N
Instantaneous voltage between L3 and neutral
Voltage, L1-L2
Instantaneous voltage between L1 and L2
Voltage, L2-L3
Instantaneous voltage between L2 and L3
Voltage, L1-L3
Instantaneous voltage between L1 and L3
Active Power, Total
Instantaneous total active power
Active Power, L1
Instantaneous active power in L1
Active Power, L2
Instantaneous active power in L2
Active Power, L3
Instantaneous active power in L3
Active energy net Total
Total cumulative active net energy
Active energy net L1
Cumulative active net energy in L1
Active energy net L2
Cumulative active net energy in L2
Active energy net L3
Cumulative active net energy in L3
Power factor tot.
Instantaneous total power factor
Power factor L1
Instantaneous power factor in L1
Power factor L2
Instantaneous power factor in L2
Power factor L3
Instantaneous power factor in L3
Active energy currency conversion
Price in currency per kWh
factor
Active import energy, total in Cur-
Total cumulative active imported energy expressed
rency
in currency
Active energy CO2 conversion fac-
CO2 emission in kg per kWh
tor
Active import energy, total in CO2
Total cumulative active imported energy expressed
in CO2
Reactive Power, Total
Instantaneous total reactive power
Reactive Power, L1
Instantaneous reactive power in L1
Reactive Power, L2
Instantaneous reactive power in L2
Reactive Power, L3
Instantaneous reactive power in L3
Reactive energy net Tot.
Total cumulative reactive net energy
Reactive energy net L1
Cumulative reactive net energy in L1
Reactive energy net L2
Cumulative reactive net energy in L2
Reactive energy net L3
Cumulative reactive net energy in L3
Apparent Power, Total
Instantaneous total apparent power
