User data The User Data contains the data to be sent to the recipient.
The following table shows the structure of the data sent from the meter to
the master:
Fixed data header
Data records
MDH
12 bytes
Variable number of bytes
1 byte
The following table shows the structure of the data sent from the master to the
meter:
Data records
Variable number of bytes
Fixed data header The following table shows the structure of the fixed data header:
ID No.
Manufacturer
Version
Medium
Access No.
Status
Signature
4 bytes
2 bytes
1 byte
1 byte
1 byte
1 byte
2 byte
The following list explains the content of the fixed data header:
• Identification No. is the 8-digit serial number of the meter (BCD coded).
• Manufacturer is set to 0442h meaning ABB
• Version specifies the version of the protocol implementation. The meters
currently use the protocol version equal to 0x20.
• Medium byte is set to 02h to indicate electricity.
• Access number is a counter that counts successful accesses.
• Status byte is used to indicate the meter status.
Bit Meaning
0 Meter busy
1 Internal error
2 Power low
3 Permanent error
4 Temporary error
5 Installation error
6 Not used
7 Not used
• Signature is set to 00 00h
