Communication with M-Bus
2CMC48001M0201 199 A43/A44
Revision: C User Manual
Byte No.
Size
Value
Description
101
1
70
DIFE, tariff 3, unit 1
102
1
84
VIF for units kWh with resolution 0,01kWh
103
1
xx
VIFE status
104-109
6
xxxxxxxxxxxx
Active exported energy, Tariff 3
110
1
8E
DIF size, 12 digit BCD
111
1
C0
DIFE, unit 1
112
1
10
DIFE, tariff 4
113
1
84
VIF for units kWh with resolution 0,01kWh
114
1
xx
VIFE status
115-120
6
xxxxxxxxxxxx
Active exported energy, Tariff 4
121
1
01
DIF size, 8 bit integer
122
1
FF
VIF next byte is manufacturer specific
123
1
93
VIFE current tariff
124
1
xx
VIFE status
125
1
xx
Current tariff
126
1
04
DIF size, 32 bit integer
127
1
FF
VIF next byte is manufacturer specific
128
1
A0
VIFE CT ratio primary current
129
1
xx
VIFE status
130-133
4
xxxxxxxx
Current transformer ratio primary current
134
1
04
DIF size, 32 bit integer
135
1
FF
VIF next byte is manufacturer specific
136
1
A1
VIFE VT ratio primary voltage
137
1
xx
VIFE status
138-141
4
xxxxxxxx
Voltage transformer ratio primary voltage
142
1
04
DIF size, 32 bit integer
143
1
FF
VIF next byte is manufacturer specific
144
1
A2
VIFE CT ratio secondary current
145
1
xx
VIFE status
146-149
4
xxxxxxxx
Current transformer ratio secondary current
150
1
04
DIF size, 32 bit integer
151
1
FF
VIF next byte is manufacturer specific
152
1
A3
VIFE VT ratio secondary voltage
153
1
xx
VIFE status
154-157
4
xxxxxxxx
Voltage transformer ratio secondary voltage
158
1
07
DIF size, 64 bit integer
159
1
FF
VIF next byte is manufacturer specific
160
1
A6
VIFE error flags (binary)
161
1
xx
VIFE status
162-169
8
xxxxxxxxxxxxxxxx
64 Error flags
170
1
07
DIF size, 64 bit integer
