ABB A43

Communication with M-Bus
A43/A44 206 2CMC48001M0201
User Manual Revision: C
Byte No.
Size
Value
Description
16
1
xx
Number of accesses
17
1
xx
Status
18-19
2
0000
Signature (0000 = no encryption)
20
1
0E
DIF size, 12 digit BCD
21
1
FF
VIF next byte is manufacturer specific
22
1
EC
VIFE Power outage time
23
1
xx
VIFE status
24-29
6
xxxxxxxxxxxx
Power outage time (sec, min, hour, days, LSB first)
30
1
02
DIF size, 16 bit integer
31
1
FF
VIF next byte is manufacturer specific
32
1
E0
VIFE power factor with resolution 0,001
33
1
xx
VIFE status
34-35
2
xxxx
Power factor, Total
36
1
02
DIF size, 16 bit integer
37
1
FF
VIF next byte is manufacturer specific
38
1
E0
VIFE power factor with resolution 0,001
39
1
FF
VIFE next byte is manufacturer specific
40
1
81
VIFE L1
41
1
xx
VIFE status
42-43
2
xxxx
Power factor, L1
44
1
02
DIF size, 16 bit integer
45
1
FF
VIF next byte is manufacturer specific
46
1
E0
VIFE power factor with resolution 0,001
47
1
FF
VIFE next byte is manufacturer specific
48
1
82
VIFE L2
49
1
xx
VIFE status
50-51
2
xxxx
Power factor, L2
52
1
02
DIF size, 16 bit integer
53
1
FF
VIF next byte is manufacturer specific
54
1
E0
VIFE power factor with resolution 0,001
55
1
FF
VIFE next byte is manufacturer specific
56
1
83
VIFE L3
57
1
xx
VIFE status
58-59
2
xxxx
Power factor, L3
60
1
02
DIF size, 16 bit integer
61
1
FF
VIF next byte is manufacturer specific
62
1
D2
VIFE phase angle power with resolution 0.1
63
1
xx
VIFE status
64-65
2
xxxx
Phase angle power, Total
66
1
02
DIF size, 16 bit integer
67
1
FF
VIF next byte is manufacturer specific
