ABB A43

Communication with M-Bus
2CMC48001M0201 211 A43/A44
Revision: C User Manual
Byte No.
Size
Value
Description
38
1
xx
Current quadrant, L2
39
1
01
DIF size, 8 bit integer
40
1
FF
VIF next byte is manufacturer specific
41
1
97
VIFE current quadrant
42
1
FF
VIF next byte is manufacturer specific
43
1
83
VIFE L3
44
1
xx
VIFE status
45
1
xx
Current quadrant, L3
46
1
81
DIF size, 8 bit integer
47
1
40
DIFE (Unit = 1)
48
1
FD
VIF extension of VIF-codes
49
1
9A
VIFE digital output
50
1
xx
VIFE status
51
1
xx
Output 1, current state
52
1
81
DIF size, 8 bit integer
53
1
80
DIFE,
54
1
40
DIFE (Unit = 2)
55
1
FD
VIF extension of VIF-codes
56
1
9A
VIFE digital output
57
1
xx
VIFE status
58
1
xx
Output 2, current state
59
1
81
DIF size, 8 bit integer
60
1
C0
DIFE (Unit = 1)
61
1
40
DIFE (Unit = 2)
62
1
FD
VIF extension of VIF-codes
63
1
9A
VIFE digital output
64
1
xx
VIFE status
65
1
xx
Output 3, current state
66
1
81
DIF size, 8 bit integer
67
1
80
DIFE,
68
1
80
DIFE,
69
1
40
DIFE (Unit = 4)
70
1
FD
VIF extension of VIF-codes
71
1
9A
VIFE digital output
72
1
xx
VIFE status
73
1
xx
Output 4, current state
74
1
81
DIF size, 8 bit integer
75
1
40
DIFE (Unit = 1)
76
1
FD
VIF extension of VIF-codes
77
1
9B
VIFE digital input
78
1
xx
VIFE status
