ABB A43

Communication with M-Bus
2CMC48001M0201 213 A43/A44
Revision: C User Manual
Byte No.
Size
Value
Description
120
1
xx
VIFE status
121
1
xx
Input 3, stored state (1 if current state has been 1)
122
1
C1
DIF size, 8 bit integer, storage number 1
123
1
80
DIFE,
124
1
80
DIFE,
125
1
40
DIFE (Unit = 4)
126
1
FD
VIF extension of VIF-codes
127
1
9B
VIFE digital input
128
1
xx
VIFE status
129
1
xx
Input 4, stored state (1 if current state has been 1)
130
1
8E
DIF size, 12 digit BCD
131
1
40
DIFE (Unit = 1)
132
1
FD
VIF extension of VIF-codes
133
1
E1
VIFE cumulating counter
134
1
xx
VIFE status
135-140
6
xxxxxxxxxxxx
Counter 1 (input 1)
141
1
8E
DIF size, 12 digit BCD
142
1
80
DIFE,
143
1
40
DIFE (Unit = 2)
144
1
FD
VIF extension of VIF-codes
145
1
E1
VIFE cumulating counter
146
1
xx
VIFE status
147-152
6
xxxxxxxxxxxx
Counter 2 (input 2)
153
1
8E
DIF size, 12 digit BCD
154
1
C0
DIFE (Unit = 1)
155
1
40
DIFE (Unit = 2)
156
1
FD
VIF extension of VIF-codes
157
1
E1
VIFE cumulating counter
158
1
xx
VIFE status
159-164
6
xxxxxxxxxxxx
Counter 3 (input 3)
165
1
8E
DIF size, 12 digit BCD
166
1
80
DIFE,
167
1
80
DIFE,
168
1
40
DIFE (Unit = 4)
169
1
FD
VIF extension of VIF-codes
170
1
E1
VIFE cumulating counter
171
1
xx
VIFE status
172-177
6
xxxxxxxxxxxx
Counter 4 (input 4)
178
1
1F
DIF, more records will follow in next telegram
179
1
xx
CS checksum, calculated from C field to last data
180
1
16
Stop character
