ABB A43

Communication with M-Bus
A43/A44 222 2CMC48001M0201
User Manual Revision: C
Byte No.
Size
Value
Description
87
1
C0
DIFE, Unit 1
88
1
C0
DIFE, Unit 2
89
1
40
DIFE, Unit 4
90
1
84
VIF for unit kvarh with resolution 0,01kvarh
91
1
FF
VIFE next byte is manufacturer specific
92
1
81
VIFE L1
93
1
xx
VIFE status
94-99
6
xxxxxxxxxxxx
Reactive net energy, L1
100
1
8E
DIF size, 12 digit BCD
101
1
C0
DIFE, Unit 1
102
1
C0
DIFE, Unit 2
103
1
40
DIFE, Unit 4
104
1
84
VIF for unit kvarh with resolution 0,01kvarh
105
1
FF
VIFE next byte is manufacturer specific
106
1
82
VIFE L2
107
1
xx
VIFE status
108-113
6
xxxxxxxxxxxx
Reactive net energy, L2
114
1
8E
DIF size, 12 digit BCD
115
1
C0
DIFE, Unit 1
116
1
C0
DIFE, Unit 2
117
1
40
DIFE, Unit 4
118
1
84
VIF for unit kvarh with resolution 0,01kvarh
119
1
FF
VIFE next byte is manufacturer specific
120
1
83
VIFE L3
121
1
xx
VIFE status
122-127
6
xxxxxxxxxxxx
Reactive net energy, L3
128
1
8E
DIF size, 12 digit BCD
129
1
80
DIFE
130
1
80
DIFE
131
1
80
DIFE
132
1
40
DIFE, Unit 8
133
1
84
VIF for unit kVAh with resolution 0,01kVAh
134
1
xx
VIFE status
135-140
6
xxxxxxxxxxxx
Apparent net energy, Total
141
1
8E
DIF size, 12 digit BCD
142
1
80
DIFE
143
1
80
DIFE
144
1
80
DIFE
145
1
40
DIFE, Unit 8
146
1
84
VIF for unit kVAh with resolution 0,01kVAh
147
1
FF
VIFE next byte is manufacturer specific
