ABB A43

Communication with M-Bus
A43/A44 260 2CMC48001M0201
User Manual Revision: C
Byte No.
Size
Value
Description
108
1
02
DIF size, 2 byte integer
109
1
FF
VIF next byte is manufacturer specific
110
1
ED
VIFE current harmonics
111
1
FF
VIF next byte is manufacturer specific
112
1
8x
VIFE phase x
113
1
FF
VIF next byte is manufacturer specific
114
1
F8
Extension of manufacturer specific VIFE's, next
VIFE(s) used for numbering
115
1
89
VIFE signifies harmonic number 9
116
1
xx
VIFE containing status
117-118
2
xxxx
9:th harmonic in percent with 1 decimal
119
1
02
DIF size, 2 byte integer
120
1
FF
VIF next byte is manufacturer specific
121
1
ED
VIFE current harmonics
122
1
FF
VIF next byte is manufacturer specific
123
1
8x
VIFE phase x
124
1
FF
VIF next byte is manufacturer specific
125
1
F8
Extension of manufacturer specific VIFE's, next
VIFE(s) used for numbering
126
1
8A
VIFE signifies harmonic number 10
127
1
xx
VIFE containing status
128-129
2
xxxx
10:th harmonic in percent with 1 decimal
130
1
02
DIF size, 2 byte integer
131
1
FF
VIF next byte is manufacturer specific
132
1
ED
VIFE current harmonics
133
1
FF
VIF next byte is manufacturer specific
134
1
8x
VIFE phase x
135
1
FF
VIF next byte is manufacturer specific
136
1
F8
Extension of manufacturer specific VIFE's, next
VIFE(s) used for numbering
137
1
8B
VIFE signifies harmonic number 11
138
1
xx
VIFE containing status
139-140
2
xxxx
11:th harmonic in percent with 1 decimal
141
1
02
DIF size, 2 byte integer
142
1
FF
VIF next byte is manufacturer specific
143
1
ED
VIFE current harmonics
144
1
FF
VIF next byte is manufacturer specific
145
1
8x
VIFE phase x
146
1
FF
VIF next byte is manufacturer specific
147
1
F8
Extension of manufacturer specific VIFE's, next
VIFE(s) used for numbering
148
1
8C
VIFE signifies harmonic number 12
