ABB A43

Communication with M-Bus
A43/A44 268 2CMC48001M0201
User Manual Revision: C
Byte No.
Size
Value
Description
59
1
F8
Extension of manufacturer specific VIFE's, next
VIFE(s) used for numbering
60
1
84
VIFE signifies harmonic number 4
61
1
xx
VIFE containing status
62-63
2
xxxx
4:th harmonic in percent with 1 decimal
64
1
02
DIF size, 2 byte integer
65
1
FF
VIF next byte is manufacturer specific
66
1
EE
VIFE voltage harmonics
67
1
FF
VIF next byte is manufacturer specific
68
1
8x
VIFE phase x
69
1
FF
VIF next byte is manufacturer specific
70
1
F8
Extension of manufacturer specific VIFE's, next
VIFE(s) used for numbering
71
1
85
VIFE signifies harmonic number 5
72
1
xx
VIFE containing status
73-74
2
xxxx
5:th harmonic in percent with 1 decimal
75
1
02
DIF size, 2 byte integer
76
1
FF
VIF next byte is manufacturer specific
77
1
EE
VIFE voltage harmonics
78
1
FF
VIF next byte is manufacturer specific
79
1
8x
VIFE phase x
80
1
FF
VIF next byte is manufacturer specific
81
1
F8
Extension of manufacturer specific VIFE's, next
VIFE(s) used for numbering
82
1
86
VIFE signifies harmonic number 6
83
1
xx
VIFE containing status
84-85
2
xxxx
6:th harmonic in percent with 1 decimal
86
1
02
DIF size, 2 byte integer
87
1
FF
VIF next byte is manufacturer specific
88
1
EE
VIFE voltage harmonics
89
1
FF
VIF next byte is manufacturer specific
90
1
8x
VIFE phase x
91
1
FF
VIF next byte is manufacturer specific
92
1
F8
Extension of manufacturer specific VIFE's, next
VIFE(s) used for numbering
93
1
87
VIFE signifies harmonic number 7
94
1
xx
VIFE containing status
95-96
2
xxxx
7:th harmonic in percent with 1 decimal
97
1
02
DIF size, 2 byte integer
98
1
FF
VIF next byte is manufacturer specific
99
1
EE
VIFE voltage harmonics
100
1
FF
VIF next byte is manufacturer specific
