Meter Settings
2CMC48001M0201 37 A43/A44
Revision: C User Manual
Table: 4:3
Alarm alternatives
Interval/Unit
Inactive
-
Active power total
1
- 9999 W/kW/MW
Reactive Power Total
1
- 9999 var/kvar/Mvar
Apparent Power Total
1
- 9999 VA/kVA/MVA
Power factor total
0.000 - 0.999
Current L1
0.01 - 99.99 A/kA
Current L2
0.01 - 99.99 A/kA
Current L3
0.01 - 99.99 A/kA
Current N
0.01 - 99.99 A/kA
Voltage L1
0.1 - 999.9 V/kV
Voltage L2
0.1 - 999.9 V/kV
Voltage L3
0.1 - 999.9 V/kV
Voltage L1-L2
0.1 - 999.9 V/kV
Voltage L2-L3
0.1 - 999.9 V/kV
Voltage L1-L3
0.1 - 999.9 V/kV
Harmonic voltage L1
0
- 999 %
Harmonic voltage L2
0
- 999 %
Harmonic voltage L3
0
- 999 %
Harmonic voltage L1-L2
0
- 999 %
Harmonic voltage L2-L3
0
- 999 %
Harmonic voltage L1-L3
0
- 999 %
Harmonic current L1
0
- 999 %
Harmonic current L2
0
- 999 %
Harmonic current L3
0
- 999 %
Active power L1
1
- 9999 W/kW/MW
Active power L2
1
- 9999 W/kW/MW
Active power L3
1
- 9999 W/kW/MW
Reactive power L1
1
- 9999 var/kvar/Mvar
Reactive power L2
1
- 9999 var/kvar/Mvar
Reactive power L3
1
- 9999 var/kvar/Mvar
Apparent power L1
1
- 9999 VA/kVA/MVA
Apparent power L2
1
- 9999 VA/kVA/MVA
Apparent power L3
1
- 9999 VA/kVA/MVA
Power factor L1
0.000-0.999
Power factor L2
0.000-0.999
Power factor L3
0.000-0.999
Table: 4:4
4 configurable I/Os
4 static I/Os
1 static I/O
No output
No output
No output
Out 1
Out 1
Out 1
