ABB A43

Technical Description
2CMC48001M0201 49 A43/A44
Revision: C User Manual
Instrumentation
3-phase, 4-wire
3-phase, 3-wire
Phase angle current, L3
X
X
Current quadrant, Total
X
X
Current quadrant, L1
X
X
Current quadrant, L2
X
Current quadrant, L3
X
X
THD for voltages
X
X
Harmonics voltage L1 (number 2-16)
X
Harmonics voltage L2 (number 2-16)
X
Harmonics voltage L3 (number 2-16)
X
Harmonics voltage L1-L2 (number 2-16)
X
X
Harmonics voltage L2-L3 (number 2-16)
X
X
Harmonics voltage L1-L3 (number 2-16)
X
X
THD for currents
X
X
Harmonics current L1 (number 2-16)
X
X
Harmonics current L2 (number 2-16)
X
Harmonics current L3 (number 2-16)
X
X
Harmonics current N (number 2-16)
X
Accuracy
All instrumentation data accuracy is defined within the voltage range 20 % of the
stated nominal voltage and within the current range 5 % of the base current to the
maximum current.
The accuracy of all instrumentation data except the frequency and voltage and
current phase-angles is the same as the stated energy metering accuracy. The ac-
curacy for the voltage and current phase-angles is 2 degrees and 0.5 % for the
frequency.
