Technical Description
2CMC48001M0201 73 A43/A44
Revision: C User Manual
channel is used. By default the meter has all 8 channels activated with 5000 snap-
shots assigned to each.
If there is no free memory space available, the oldest snapshot will be erased
to make room for the most recent one.
It is possible to erase all snapshots in all channels by sending a “Reset Load
profile” command via communication. Via Modbus and EQ-bus communication
it is also possible to erase all snapshots in a particular channel.
Load profile data Each load profile data value is associated with a status value. The status value
gives information such as:
• Interval is longer or shorter than defined length
• Power outage occurred during interval
• Overflow in data
• Time was changed during interval
• Data not available
• Error in data
