Parameters List 43
EN
TR
ZH
46.05 Current scaling 0…30000 A 10000
46.06 Speed ref zero scaling 0.00...30000.00 rpm 0.00
46.07 Frequency ref zero scaling 0.00...1000.00 Hz 0.00
46.11 Filter time motor speed 2…20000 ms 500
46.12 Filter time output frequency 2…20000 ms 500
46.13 Filter time motor torque 2…20000 ms 100
46.14 Filter time power 2…20000 ms 100
46.21 At speed hysteresis 0.00...30000.00 rpm 50.00
46.22 At frequency hysteresis 0.00...1000.00 Hz 2.00
46.31 Above speed limit 0.00...30000.00 rpm 1500.00
46.32 Above frequency limit 0.00...1000.00 Hz 50.00
46.41 kWh pulse scaling 0.001...1000.000 kWh 1.000
46.43 Power decimals 0...3 - 2
46.44 Current decimals 0...3 - 1
49 Panel port communication
49.01 Node ID number 1…32 - 1
49.03 Baud rate 1...5 - 115.2 kbps[4]
49.04 Communication loss time 0.3...3000.0 s 10.0
49.05 Communication loss action 0...3 - Fault[1]
49.06 Refresh settings Done[0], Configure[1] - Done[0]
50 Fieldbus adapter (FBA)
50.01 FBA A enable Disable[0], Enable[1] - Disable[0]
50.02 FBA A comm loss func 0...5 - No action[0]
50.03 FBA A comm loss t out 0.3...6553.5 s 0.3
50.04 FBA A ref1 type
--
Speed or
frequency[0]
50.05 FBA A ref2 type Not applicable.
50.06 FBA A SW sel Auto[0], Transparent mode[1] - Auto[0]
50.07 FBA A actual 1 type
--
Speed or
frequency[0]
50.08 FBA A actual 2 type Not applicable
50.09 FBA A SW transparent source - - Not selected
50.10 FBA A act1 transparent source - - Not selected
50.11 FBA A act2 transparent source Not applicable.
50.12 FBA A debug mode Disable[0], Fast[1] - Disable
50.13 FBA A control word 0.0.0.0.0...FF.FF.FF.FF - 0.0.0.0
Index Name Range/List Unit Default
38.4 kbps[1] 57.6 kbps[2] 86.4 kbps[3] 115.2 kbps[4] 230.4 kbps[5]
No action[0] Fault[1] Last speed[2] Speed ref safe[3] - Not applicable.
No action[0] Fault[1] Last speed[2] Speed ref safe[3] Fault always[4] Warning[5]
Speed or frequency[0] Transparent[1] General[2] Speed[4] Frequency[5]
Note: Applicable only when 79.40 MPPT reference is disabled. If parameter MPPT reference is
enabled, then the parameter should be set to it’s default value.
Speed or frequency[0] Transparent[1] General[2] Speed[4] Frequency[5]
Note: Applicable only when 79.40 MPPT reference is disabled. If parameter MPPT reference is
enabled, then the parameter should be set to it’s default value.
ACQ80R0-R8 QIG.book Page 43 Friday, February 1, 2019 1:18 PM
