ABB ACQ80-04 - Page 44

44 Parameters List
EN
ES
FI
FR
IT
PL
PT
RU
SV
TR
ZH
50.14 FBA A reference 1 -2147483648…2147483647 - 0
Note: Applicable only when 79.40 MPPT reference is disabled. If parameter MPPT reference is
enabled, then the parameter should be set to it’s default value.
50.15 FBA A reference 2 Not applicable.
50.16 FBA A status word 0.0.0.0.0...FF.FF.FF.FF - 0.0.0.0
50.17 FBA A actual value 1 -2147483648...2147483647 - 0
50.18 FBA A actual value 2 Not applicable.
51 FBA A settings
51.01 FBA A type 0, 1, 32, 37, 101, 128, 132,
135, 136, 485, 47808
- None[0]
51.02 FBA A Par2 0…65535 - 0
… … … … ...
51.26 FBA A Par26 0…65535 - 0
51.27 FBA A par refresh Done[0], Configure[1] - Done[0]
51.28 FBA A par table ver 0x0000...0xffff - 0x0000
51.29 FBA A drive type code 0…65535 - 0
51.30 FBA A mapping file ver 0…65535 - 0
51.31 D2FBA A comm status
0...6 -
Not configured
[0]
51.32 FBA A comm SW ver 0x0000...0xffff - 0x0000
51.33 FBA A appl SW ver 0x0000...0xffff - 0x0000
52 FBA A data in
52.01 FBA A data in1 0...6, 11...16, 24 - None
… … … … ...
52.12 FBA A data in12 See parameter 52.01 FBA A
data in1
-None
53 FBA A data out
53.01 FBA A data out1 0...3, 11...13, 21 - None[0]
… … … … ...
53.12 FBA A data out12 See parameter 53.01 FBA A
data out1
-None
58 Embedded fieldbus
58.01 Protocol None[0], Modbus RTU[1] - None[0]
58.02 Protocol ID 0000h…FFFFh - 0
58.03 Node address 0…255 - 0
Index Name Range/List Unit Default
None[0] Ethernet[128] RS-485 comm[485]
PROFIBUS-DP[1] PROFInet IO[132] Modbus/TCp[502]
CANopen[32] EtherCAT[135] Ethernet/IP[2222]
Not configured[0] Time out[2] Off-line[4] Reset[6]
Initializing[1] Configuration error[3] On-line[5]
None[0] Ref2 16bit[3] Act2 16bit[6] Ref2 32bit[13] Act2 32bit[16]
CW 16bit[1] SW 16bit[4] CW 32bit[11] SW 32bit[14] SW2 16bit[24]
Ref1 16bit[2] Act1 16bit[5] Ref1 32bit[12] Act1 32bit[15] Other...
None[0] Ref1 16bit[2] CW 32bit[11] Ref2 32bit[13] Other...
CW 16bit[1] Ref2 16bit[3] Ref1 32bit[12] CW2 16bit[21]
ACQ80R0-R8 QIG.book Page 44 Friday, February 1, 2019 1:18 PM
