39
Level 6 – Basic Configuration
Template Application
Templates are provided to make the basic configuration for a particular
application as simple as possible. The appropriate template should be
selected before any other parameters are configured. When a template is
selected, the COMMANDER 350 assumes the preset form for that
template (see Appendix A). The inputs and software blocks are
automatically soft-wired to perform the selected function.
Select the Template required
Note 1. When a template is selected, the following default values
apply: The 'Analog Input Type' of all inputs used by the template defaults
to '2', i.e. 4 to 20mA; The engineering ranges of all inputs used default to
'0.0 to 100.0'. All other inputs are set to '
OFF'.
Note 2. Templates customized using the PC Configurator are
identified by the letter '
U' in the template code – i.e. template '01.SL'
becomes '
01.U'.
Continued…
4.2 Level 6 – Basic Configuration 6.00...6.01
4 CONFIGURATION MODE…
APPL
LEV.6
6.00
1.SL
t.APP
6..01
yalpsiDnoitpircseDetalpmeT
LS.10
ylnotniopteslacolhtiwpoolelgniS
LS.20
tnioptesetomerhtiwpoolelgniS
MA.30
noitceleslangiswolhtiwnoitatslaunaM/otuA
MA.40
noitceleslatigidhtiwnoitatslaunaM/otuA
bA.50
noitceleslangiswolhtiwpukcabgolanA
bA.60
noitceleslatigidhtiwpukcabgolanA
NI.70
redaollaunam/rotacidnielgniS
NI.80
redaollaunam/rotacidnielbuoD
To Next Page
