67
SErL
LEVd
d.00
1
Addr
d.03
NONE
PrtY
d.02
0
S.CFG
d.01
SErL
LEVd
d.00...d.03
4 CONFIGURATION MODE…
4.9 Level D – Serial Communications Configuration
Note. Level D is only applicable if the serial communications option is fitted.
Level D – Serial Communications Configuration
Note. To select this frame from anywhere in this page, press and
hold the
key for a few seconds.
Serial Configuration
0 – Off
1 – 2-wire connection, 2400 baud rate
2 – 4-wire connection, 2400 baud rate
3 – 2-wire connection, 9600 baud rate
4 – 4-wire connection, 9600 baud rate
5 – 2-wire connection, 19200 baud rate
6 – 4-wire connection, 19200 baud rate
Parity
NONE – None
Odd – Odd
EVEN – Even
Modbus
TM
Address
Each slave on a Modbus link must be assigned a unique address – see
IM/C350–MOD.
[1 to 99]
Return to top of page.
