ABB COMMANDER 351 - A3 Indicator;Manual Loader Station (Templates 7 and 8)

85
APPENDIX A – CONTROL TEMPLATES
PV1
PV2
I/P2
I/P1
Manual Output
ao1
•1 Template 8 Only
•1
•2 Not applicable if Control Output Type is set to 'None' –
see Section 4.2/Basic Configuration.
•2
A3 Indicator/Manual Loader Station (Templates 7 and 8)
The Indicator/manual Loader Station is used to display one or two process variables on the digital and bargraph displays. If the control output is
assigned to an analog output, the lower display indicates its value which can be adjusted by the user. This output can be used
to manually control a process
or to provide a set point value for another controller.
