ABB Switzerland Ltd 1KHW001489-EN ETL600
9.6.1.4. PLC warnings
HMI600 Alarm Text Explanation and corrective actions
(the latter in italics)
• EOC communication
failure
• Could not receive
data from EOC
• Could not send data
to EOC
The transmission of data via embedded operation (EOC)
channel 1 is disturbed.
Make sure that identical firmware versions are in use in
both local and remote equipments. Check if the quality of
the receive signal in terms of SNR and receive level is
adequate.
Reset ETL600. If the error persists, replace
P4LT.
• AGC or pilot(s)
switched off or tuning
tone(s) switched on
At least one of the tests switches under
Equipment /
Tuning and Testing / Test PLC-link
or Equipment /
Commissioning and maintenance / Test PLC-link
is
active.
• Equipment in tuning
or testing mode
The ETL600 is not in normal operation mode. Reasons for
that might be
- any test switch is active,
- any Tuning and Testing procedure is ongoing,
- frequency response measurement is ongoing,
- the dummy load is plugged
• Different firmware
versions on local
and remote
equipment
Different firmware versions on local and remote equipment
are in use.
Use identical firmware in both equipments.
• Active configuration
not stored to
EPROM
A test configuration is active which will be lost when the
associated test configuration timer runs out.
Store the configuration to EPROM, stopping the test
configuration timer, or reset the system, thereby
overwriting the test configuration.
• Dummy load
plugged
A dummy load has been inserted for test purposes,
replacing the RF hybrid and interrupting the link.
When the tests are terminated, remove the dummy load
and reinsert the RF hybrid.
• O4LE warning
A warning is present on at least one of the O4LE boards.
Check O4LE status for detailed information.
• Power amplifier
warning
P4LT receives a warning from the 80 W power amplifier.
One of the two 40 W amplifiers P1LA used to generate the
80 W output may be faulty.
Replace the faulty modules
• Event recorder block
rotation
The event recorder has performed a block rotation. This
happens automatically if the nonvolatile memory assigned
to the event recorder is full. Some of the memory is freed
by discarding the oldest recorded events.
9-20 November 2005 Troubleshooting
