ABB Switzerland Ltd 1KHW001489-EN ETL600
11-2 November 2005 Options
11.2.1.5. Dummy load P3LK
The transmitter is looped to the own receiver by inserting the dummy
load P3LK in place of the RF hybrid P3LE, which enables both
transmitter and receiver to be fully tested.
11.2.1.6. Cables
Refer to chapter 6 for the type of the cables.
Module Cable(s)
O4LE /
V9OD,
V9OS
The cable is required for external wiring of the
teleoperation inputs & outputs.
The cable is also used for transit operation or to connect
the NSD570 / NSD70C protection equipment.
The cable is required for external wiring of the 4W E&M
circuit.
The cable is required for external wiring of the 2W port
configured in subscriber interface or PAX interface.
G4AI /
V9OF
The cable is required for external wiring of the
teleprotection signals
R1BC /
V9MR
The cable is required for extension of contacts of the
programmable alarm relays.
P4LT /
V9OT
(Off-the-
shelf
cable)
V9OU
V9OW
V9OV
This cable is required for extension of contacts of the
alarm relays on P4LT.
For the connection of a PC to the “HMI” SUB-D connector
on the front plate, an additional “off-the-shelf” 1 to 1 / 9-
pole cable is required or, alternatively, for connection of
an external modem to the SUB-D connector on the front
plate, an additional null modem / 9-pole cable is required.
This cable can be used for the connection of a PC to the
HMI port on the front plate and is required for connection
of external devices to the V.24 ports.
This cable is required for the connection of external
devices to the V.11 ports on the front plate.
This cable is required for connection of external devices
to the HMI port (when used as RS-485 station bus port)
and to the IRIG-B port on the front plate.
P7LA In addition to the AC/DC power supply cable, the RF
coaxial cable is also required.
For 80 W operation, a jumper cable is required between
the upper and lower P7LA.
P7LC A flat cable is required for connection between P7LA and
P7LC. Also a small power supply cable is required for
extension of DC supply from P7LA to P7LC.
