114 Communication profiles
7 ALARM 1 Warning/alarm
0 No warning/alarm
8 AT_SETPOINT 1 OPERATION. Actual value equals
reference value (= is within tolerance
limits, i.e., in speed control, speed error is
10% maximum of the nominal motor
speed). Note that tolerance limit can be
configured in the drive side, for example,
speed window in this case.
0 Actual value differs from reference (= is
outside tolerance limits).
9 REMOTE 1 Drive control location: REMOTE (EXT1
or EXT2)
0 Drive control location: LOCAL
10 ABOVE_LIMIT 1 Actual frequency or speed equals or
exceeds supervision limit (set by drive
parameter). Valid in both directions of
rotation.
0 Actual frequency or speed within
supervision limit
11 EXT_CTRL_
LOC
1 External Control Location EXT2 selected
0 External Control Location EXT1 selected
12 EXT_RUN_
ENABLE
1 External Run Enable signal received
0 No External Run Enable signal received
13…
14
Drive-specific (For information, see the drive documentation.)
15 FBA_ERROR 1 Communication error detected by
fieldbus adapter module
0 Fieldbus adapter communication OK
Bit Name Value STATE/Description
