Start-up 71
Starting up ACS380 drives
The ACS380 software automatically sets the relevant parameters
when the fieldbus adapter module is connected to the drive.
Automatic configuration is only minimum configuration, and you
can change these parameters later, e.g., Node address.
Parameter General setting
20.01 Ext1 commands Fieldbus A
20.03 Ext1 in1 Not selected
20.04 Ext1 in2 Not selected
22.11 Ext1 speed ref1 FB A ref1
22.22 Constant speed sel1 Not selected
22.23 Constant speed sel2 Not selected
23.11 Ramp sel selection Acc/Dec time 1
28.11 Ext1 frequency ref1 FB A ref1
28.22 Constant frequency sel1 Not selected
28.23 Constant frequency sel2 Not selected
28.71 Freq ramp set sel Acc/Dec time 1
31.11 Fault reset selection DI1
50.01 FB A enable Enable
50.02 FB A comm loss func Fault
51.02 Node address 3
51.05 Profile ABB Drives
52.01 FBA A data in1 SW 16 bit
52.02 FBA A data in 2 Act1 16 bit
53.01 FBA A data out1 CW 16 bit
53.02 FBA A data out2 Ref1 16 bit
