ABB FPBA-01 PROFIBUS DP User Manual

60 Start-up
 Parameter setting examples – ACSM1
Speed control using the PROFIdrive communication profile
with PPO Type 2
This example shows how to configure a basic speed control
application that uses the PROFIdrive profile. In addition, some
application-specific data is added to the communication.
The start/stop commands and reference are according to the
PROFIdrive profile, speed control mode. For more information, see
the PROFIdrive state machine on page 107.
The reference value ±16384 (4000h) corresponds to parameter
25.02 SPEED SCALING in the forward and reverse directions.
The table below gives the recommended drive parameter settings.
Direction PZD1 PZD2 PZD3 PZD4 PZD5 PZD6
Out Control
word
Speed
reference
Constant
speed
1)
Speed reference for
Jogging function 1
1)
In Status
word
Speed
actual value
Power
1)
DC bus voltage
1)
1)
Example
Drive parameter Setting for
ACSM1 drives
Description
50.01 FBA ENABLE Enable Enables communication
between the drive and the
fieldbus adapter module.
50.02 COMM LOSS
FUNC
Last speed Enables fieldbus
communication fault
monitoring.
50.03 COMM LOSS T
OUT
3.0 s Defines the fieldbus
communication break
supervision time.
50.04 FBA REF1
MODESEL
Speed Selects the fieldbus
reference 1 scaling.
51.01 FBA TYPE PROFIBUS-DP
1)
Displays the type of the
fieldbus adapter module.
