Page #140 background image
140 Communication protocol
The allocation of drive control/actual words, drive parameters and
PROFIdrive parameters to the parameter identification part of the
PPO type is shown below.
The Index column corresponds to the parameter number
(PNU) in the ID part of parameter identification.
The Sub-index column corresponds to the IND part of
parameter identification.
The Example No. column refers to the examples on the
following pages.
Virtual drive control area
Index Sub-index Par. No.
(Decimal)
Request label Example.
No.
0h 1h 1 R/W 6/7/8
1)
1, 2
0h 2h 2
• • •
0h 63h 99
1)
Supported with an ACSM1 drive only
Drive parameters
Index Sub-index Par. No.
(Decimal)
Request label Example
No.
1 1 101 R/W 6/7/8
1)
1, 2
12102
• • •
63h 63h 9999
1)
Supported with an ACSM1 drive only
