Start-up 41
06 T16 Scale Defines the reference
multiplier/actual value divisor for
the adapter module.
Note: The parameter is effective
only when
• Transparent 16 profile is
selected
• drive is using the native
communication profile (for
example, DCU or FBA)
• a 16-bit transparent
Reference 1/Actual value 1 is
used.
With an ACS355 drive, the speed
reference from the PLC is
multiplied by the value of this
parameter plus one. For example,
if the parameter has a value of 99
and a reference of 1000 is given by
the master, the reference will be
multiplied by 99 +1 = 100 and
forwarded to the drive as 100000.
According to the DCU profile, this
value is interpreted as a reference
of 100 rpm in the drive.
With ACSM1, ACS850, ACQ810
and ACS880, setting this
parameter to 65535 provides the
approximation of 1 ≈ 1 rpm.
99
0…65535 Reference multiplier/actual value
divisor
No. Name/Value Description Default
