ABB FPBA-01 PROFIBUS DP User Manual

54 Start-up
5104 FB PAR 4
(TELEGRAM TYPE)
2 (= PPO2)
1)
Displays the telegram type
selected by the PLC
configuration tool.
5105 FB PAR 5
(PROFILE)
0 (= PROFIdrive) Selects the Control word
according to the
PROFIdrive profile (speed
control mode).
3018 COMM FAULT
FUNC
3 = LAST SPEED Enables fieldbus
communication fault
monitoring.
3019 COMM FAULT
TIME
3.0 s Defines the fieldbus
communication break
supervision time.
5401 FBA DATA IN 1 4 (= SW 16bit)
1)
Status word
5402 FBA DATA IN 2 5 (= Act1 16bit)
1)
Actual value 1 (speed)
5403 FBA DATA IN 3 106
2)
Power
5404 FBA DATA IN 4 107
2)
DC bus voltage
5501 FBA DATA OUT 1 1 (= CW 16bit)
1)
Control word
5502 FBA DATA OUT 2 2 (= Ref1 16bit)
1)
Reference 1 (speed)
5503 FBA DATA OUT 3 1202
2)
Constant speed 1
5504 FBA DATA OUT 4 1203
2)
Constant speed 2
5127 FBA PAR
REFRESH
1 = REFRESH Validates the FPBA-01
configuration parameter
settings.
1001 EXT1 COMMANDS 10 = COMM Selects the fieldbus
interface as the source of
the start and stop
commands for external
control location 1.
1103 REF1 SELECT 8 = COMM Selects the fieldbus
reference 1 as the source
for speed reference 1.
Drive parameter Setting for
ACS355 drives
Description
