Start-up 69
53.02 FBA DATA
OUT2
2 (= Ref1 16bit
2)
Reference 1
53.03 FBA DATA
OUT3
3 (= Ref2 16bit
2)
Reference 2
51.27 FBA PAR
REFRESH
REFRESH Validates the FPBA-01
configuration parameter
settings.
10.01 EXT1 START
FUNC
FBA Selects the fieldbus interface
as the source of the start and
stop commands for external
control location 1.
10.04 EXT2 START
FUNC
FBA Selects the fieldbus interface
as the source of the start and
stop commands for external
control location 2.
24.01 SPEED REF1
SEL
FBA REF1 Selects the fieldbus reference
1 as the source for speed
reference 1.
32.02 TORQ REF ADD
SEL
FBA REF2 Selects the fieldbus reference
2 as the source for torque
reference 1.
34.01 EXT1/EXT2 SEL P. F BA M A IN
CW.15
Enables external control
location 1/2 selection through
the fieldbus only (bit 15 in the
fieldbus Control word).
34.03 EXT1 CTRL
MODE1
Speed Selects speed control as the
control mode 1 for external
control location 1.
34.05 EXT2 CTRL
MODE1
Torque Selects torque control as the
control mode 1 for external
control location 2.
1)
Read-only or automatically detected/set
2)
Example
Drive parameter Setting for
ACSM1 drives
Description
