ABB FPBA-01 PROFIBUS DP User Manual

80 Start-up
51.01 FBA A type 1 = FPBA
1)
Displays the type of the
fieldbus adapter module.
51.02 FBA A Par2 3
2)
Defines the PROFIBUS node
address of the fieldbus
adapter module.
51.03 Baud rate 12000
1)
Displays the current baud
rate on the PROFIBUS
network in kbit/s.
51.04 MSG type 1 = PPO1
1)
Displays the telegram type
selected by the PLC
configuration tool.
51.05 Profile 0 = PROFIdrive Selects the Control word
according to the PROFIdrive
profile (speed control mode).
51.07 Emul mode 0 = Disabled Disables the emulation
mode.
52.01 FBA A data in1 4 = SW 16bit
1)
Status word
52.02 FBA A data in2 5 = Act1 16bit Actual value 1
52.03 FBA A data in3 1.7 [32]
2)
Motor current
52.05 FBA A data in5 1.11 [32]
2)
DC voltage
53.01 FBA A data out1 1 = CW 16bit
1)
Control word
53.02 FBA A data out2 2 = Ref1 16bit Reference 1 (speed)
53.03 FBA A data out3 22.26 [32]
2)
Constant speed 1
53.05 FBA A data out5 22.27 [32]
2)
Constant speed 2
51.27 FBA A par
refresh
1 = Refresh Validates the FPBA-01
configuration parameter
settings.
19.12 Ext1 control
mode
2 = Speed Selects speed control as the
control mode 1 for external
control location 1.
Drive parameter Setting for
ACS880 drives
Description

ABB FPBA-01 PROFIBUS DP Specifications

General

Brand	ABB
Model	FPBA-01 PROFIBUS DP
Category	Adapter
Language	English
