NoteAction
WARNING
Handling gearbox oil involves several safety
risks. Before proceeding, please read the
safety information in the section Safety risks
during work with gearbox lubricants (oil or
grease) on page 38.
2
Shown in Location of oil plugs on
page 149.
Remove the oil plug, filling. (Ventilation hole
plug should also be removed.)
3
Tightening torque: 24 Nm.
Note
Don´t mix Kyodo Yushi TMO 150 with other oil
types!
4
Art.no. and total amount are specified
in Required equipment on page 150.
Refill gearbox with lubricating oil.
The amount of oil to be filled depends on the
amount that was previously drained.
5
Shown in Location of oil plugs on
page 149.
Refit oil plug,filling and ventilation hole plug.6
Tightening torque: 24 Nm.
152 Product manual - IRB 6660
3HAC028197-001 Revision: S
© Copyright 2007-2018 ABB. All rights reserved.
3 Maintenance
3.4.3 Changing oil, gearbox axes 2 and 3
Continued
